MECHANICAL JACK "MANUVIC"
Strongly built construction. Anti-slipping base. Easy lifting.
Safety: instantaneous stop mechanisim at any level.
Holding of the load with friction brake.
| Model | Capacity (Tonnes) |
Stress on lever (Kg) |
Weight (Kg) |
Max lifting Height (mm) A |
Picking up position height (mm) |
Dimensions (mm) |
||||
|---|---|---|---|---|---|---|---|---|---|---|
| At base B |
At top C |
D | E | F | G | |||||
| MJ10025 | 2.5T | 38 | 14 | 345 | 80 | 750 | 141 | 55 | 195 | 250 |
| MJ10050 | 5T | 55 | 22 | 360 | 90 | 780 | 182 | 70 | 225 | 300 |
| MJ10100 | 10T | 54 | 38 | 320 | 100 | 790 | 215 | 80 | 290 | 300 |
| MJ10160 | 16T | 73 | 65 | 320 | 160 | 900 | 263 | 77 | 315 | 400 |
| MJ10200 | 20T | 80 | 90 | 300 | 150 | 960 | 294 | 73 | 330 | 400 |
Illustrations and specifications may be changed without notice and are intended for guidance only. Please consult us for current product details.
