DOUBLE GIRDER CRANES
| Safe Working Load Tonnes |
Span Metres |
A | B | C | D | E | F | H | W | Hoist Gross Weight Tonnes |
Crane Gross Weight Tonnes |
Max. Static Wheel load Tonnes |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2 | 8 10 12 14 16 18 20 22 24 26 28 30 |
670 670 670 670 670 670 670 670 670 670 670 670 |
1120 1170 1225 1225 1315 1315 1400 1400 1495 1495 1620 1620 |
840 890 945 945 1035 1035 1120 1120 1215 1215 1340 1340 |
500 500 500 500 500 500 500 500 500 500 500 500 |
175 175 175 175 175 175 175 175 175 175 175 175 |
200 200 200 200 200 200 200 200 200 200 200 200 |
8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 |
2600 2600 2600 2600 2600 2600 3200 3200 3700 3700 4300 4300 |
0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 |
2.58 3.25 3.50 3.90 4.70 5.15 6.25 6.76 8.26 8.86 10.71 11.40 |
1.65 1.85 1.90 2.00 2.22 2.33 2.60 2.74 3.12 3.27 3.74 3.91 |
|
| 3.2 | 8 10 12 14 16 18 20 22 24 26 28 30 |
670 670 670 670 670 670 670 670 670 670 670 670 |
1170 1250 1225 1225 1315 1315 1400 1400 1495 1495 1620 1620 |
890 970 945 945 1035 1035 1120 1120 1215 1215 1340 1340 |
500 500 500 500 500 500 500 500 500 500 500 500 |
175 175 175 175 175 175 175 175 175 175 175 175 |
200 200 200 200 200 200 200 200 200 200 200 200 |
8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 |
2600 2600 2600 2600 2600 2600 3200 3200 3700 3700 4300 4300 |
0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 |
2.83 3.64 3.50 3.90 4.70 5.13 6.25 6.76 8.26 8.86 11.16 11.84 |
2.28 2.50 2.48 2.60 2.80 2.91 3.20 3.33 3.70 3.86 4.44 4.61 |
|
| 5 | 8 10 12 14 16 18 20 22 24 26 28 30 |
670 670 670 670 670 670 670 670 670 670 670 670 |
1225 1225 1315 1315 1395 1395 1490 1490 1667 1667 1752 1752 |
945 945 1035 1035 1115 1115 1210 1210 1335 1335 1420 1420 |
500 500 500 500 500 500 500 500 500 500 500 500 |
175 175 175 175 175 175 175 175 200 200 200 200 |
200 200 200 200 200 200 200 200 240 240 240 240 |
8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 |
2600 2600 2600 2600 2600 2600 3200 3200 3700 3700 4300 4300 |
0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 0.305 |
2.75 3.12 3.83 4.27 5.20 5.70 7.42 8.00 9.72 10.40 11.90 12.65 |
3.10 3.23 3.43 3.55 3.80 4.00 4.37 4.52 4.95 5.13 5.50 5.70 |
|
| 8 | 8 10 12 14 16 18 20 22 24 26 28 30 |
825 825 825 825 825 825 825 825 825 825 825 825 |
1332 1422 1502 1502 1592 1592 1717 1717 1802 1802 1947 1947 |
1000 1090 1170 1170 1260 1260 1385 1385 1470 1470 1615 1615 |
600 600 600 600 600 600 600 600 600 600 600 600 |
175 200 200 200 200 200 200 200 200 200 200 200 |
240 240 240 240 240 240 240 240 240 240 240 240 |
8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 |
2600 2600 2600 2600 2600 2600 3200 3200 3700 3700 4300 4300 |
0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 |
3.37 4.02 4.84 5.33 6.45 7.03 8.55 9.22 10.63 11.36 13.44 14.27 |
4.66 4.89 5.14 5.29 5.60 5.76 6.15 6.33 6.70 6.88 7.41 7.63 |
|
| 10 | 8 10 12 14 16 18 20 22 24 26 28 30 |
825 825 825 825 825 825 825 825 825 825 825 825 |
1422 1422 1502 1592 1592 1717 1717 1807 1807 1887 1887 1952 |
1090 1090 1170 1260 1260 1385 1385 1475 1475 1555 1555 1620 |
600 600 600 600 600 600 600 600 600 600 600 600 |
200 200 200 200 200 200 200 200 200 200 200 200 |
240 240 240 240 240 240 240 240 240 240 240 240 |
8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 |
2600 2600 2600 2600 2600 2600 3200 3200 3700 3700 4300 4300 |
0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 0.56 |
3.59 4.02 4.84 5.88 6.46 7.82 8.55 10.32 11.17 12.81 13.73 15.38 |
5.65 5.83 6.10 6.39 6.56 6.92 7.12 7.58 7.80 8.22 8.46 8.88 |
|
| 16 | 8 10 12 14 16 18 20 22 24 26 28 30 |
1185 1185 1185 1185 1185 1185 1185 1185 1185 1185 1185 1185 |
1687 1777 1777 1897 2055 2135 2140 2275 2285 2285 2290 2315 |
1355 1445 1445 1565 1565 1645 1650 1785 1795 1795 1800 1825 |
850 850 850 850 850 850 850 850 850 850 850 850 |
200 200 200 200 240 240 240 240 240 240 240 240 |
240 240 240 240 310 310 310 310 310 310 310 310 |
8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 |
2600 2600 2600 2600 2600 2600 3200 3200 3700 3700 4300 4300 |
1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 |
4.66 5.53 6.09 7.26 7.89 9.42 10.15 11.39 13.05 15.44 16.41 19.69 |
8.56 8.96 9.22 9.60 9.84 10.26 10.50 10.82 11.28 11.90 12.16 13.00 |
All dimensions in mm.
| Safe Working Load Tonnes |
Span Metres |
A | B | C | D | E | F | H | W | Hoist Gross Weight Tonnes |
Crane Gross Weight Tonnes |
Max. Static Wheel load Tonnes |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 20 | 8 10 12 14 16 18 20 22 24 26 28 30 |
1185 1185 1185 1185 1185 1185 1185 1185 1185 1185 1185 1185 |
1935 1935 2055 2055 2135 2135 2275 2275 2285 2285 2315 2395 |
1445 1445 1565 1565 1645 1645 1785 1785 1795 1795 1825 1905 |
850 850 850 850 850 850 850 850 850 850 850 850 |
240 240 240 240 240 240 240 240 240 240 240 240 |
310 310 310 310 310 310 310 310 310 310 310 310 |
8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 8000 |
2600 2600 2600 3200 3200 3200 3200 3200 3700 3700 4300 4300 |
1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 1.05 |
5.12 5.67 6.85 7.31 8.92 9.65 11.72 12.57 15.13 16.11 18.88 21.32 |
11.08 11.22 11.51 11.63 12.03 12.21 12.76 13.00 13.68 13.93 14.67 15.29 |
|
| 25 | 8 10 12 14 16 |
1615 1615 1615 1615 1615 |
2255 2255 2340 2340 2420 |
1765 1765 1850 1850 1931 |
1100 1100 1100 1100 1100 |
240 240 240 240 240 |
310 310 310 310 310 |
12000 12000 12000 12000 12000 |
3200 3200 3400 3400 3400 |
2.5 2.5 2.5 2.5 2.5 |
7.06 7.68 8.79 9.48 11.16 |
13.09 13.60 14.10 14.44 15.00 |
| Safe Working Load Tonnes |
Span Metres |
A | B | C | D | E | F | H | W | Hoist Gross Weight Tonnes |
Crane Gross Weight Tonnes |
Max. Static Wheel load Tonnes |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 25 | 18 20 22 24 26 28 30 |
1615 1615 1615 1615 1615 1615 1615 |
2420 2490 2490 2595 2595 2600 2600 |
1930 2000 2000 2105 2105 2210 2210 |
1100 1100 1100 1100 1100 1100 1100 |
240 240 240 240 240 240 240 |
310 310 310 310 310 310 310 |
12000 12000 12000 12000 12000 16000 16000 |
2x1500 2x1540 2x1540 2x1600 2x1600 2x1850 2x1850 |
2.5 2.5 2.5 2.5 2.5 2.5 2.5 |
12.85 15.04 15.99 19.74 20.92 23.20 24.75 |
7.8/8.8 8.0/9.24 8.15/9.4 8.41/10.14 8.57/10.33 10.36/10.36 10.57/10.57 |
|
| 32 | 8 10 12 14 16 18 20 22 24 26 28 30 |
1615 1615 1615 1615 1615 1615 1615 1615 1615 1615 1615 1615 |
2260 2260 2340 2340 2465 2465 2530 2530 2700 2700 2835 2835 |
1770 1770 1850 1850 1975 1975 2040 2040 2210 2210 2345 2345 |
1100 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100 |
240 240 240 240 240 240 240 240 240 240 240 240 |
310 310 310 310 310 310 310 310 310 310 310 310 |
12000 12000 12000 12000 12000 12000 12000 12000 16000 16000 16000 16000 |
2x1380 2x1380 2x1500 2x1500 2x1540 2x1540 2x1600 2x1600 2x1850 2x1850 2x1850 2x1850 |
2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 |
8.42 9.09 10.45 11.23 12.69 13.61 17.32 18.44 21.20 22.45 25.17 26.50 |
8.7/8.96 9.05/9.3 8.95/10.08 9.15/10.32 9.3/10.72 9.48/10.92 9.72/11.72 9.88/11.92 12.05/12.05 12.24/12.24 12.62/12.62 12.81/12.81 |
|
| 40 | 8 10 12 14 16 18 20 22 24 26 28 30 |
1615 1615 1615 1615 1615 1615 1615 1615 1615 1615 1615 1615 |
2340 2340 2420 2420 2485 2485 2640 2640 2830 2830 2840 2840 |
1850 1850 1930 1930 1995 1995 2150 2150 2340 2340 2350 2350 |
1100 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100 |
240 240 240 240 240 240 240 240 240 240 240 240 |
310 310 310 310 310 310 310 310 310 310 310 310 |
12000 12000 12000 12000 12000 12000 12000 12000 16000 16000 16000 16000 |
2x1450 2x1450 2x1500 2x1500 2x1600 2x1600 2x1600 2x1600 2x1850 2x1850 2x1850 2x1850 |
2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 |
8.72 9.46 10.65 11.45 13.61 14.51 18.07 19.26 22.23 23.57 29.04 30.64 |
10.25/11.3 10.64/11.72 10.85/12.23 11.0/12.5 11.03/13.31 11.22/13.54 11.68/14.10 11.87/14.33 14.45/14.45 14.66/14.66 15.38/15.38 15.62/15.62 |
All dimensions in mm.
